7HQ4 | pdb_00007hq4

PanDDA analysis group deposition -- Crystal structure of SARS-CoV-2 NSP3 macrodomain in complex with CACHE3HI_1696_78

• PDB DOI: https://doi.org/10.2210/pdb7HQ4/pdb
• Deposition Group: G_1002327 (changed state) ExploreG_1002327

• Classification: VIRAL PROTEIN
• Organism(s): Severe acute respiratory syndrome coronavirus 2
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2024-12-08 Released: 2025-08-20
• Deposition Author(s): Correy, G.J., Fraser, J.S.
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.00 Å
• R-Value Free:
  0.165 (Depositor), 0.171 (DCC)
• R-Value Work:
  0.147 (Depositor), 0.157 (DCC)
• R-Value Observed:
  0.148 (Depositor)

Literature

Ligand screen against SARS-CoV-2 NSP3 macrodomain

Correy, G.J., Fraser, J.S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors.

Macromolecule Content

• Total Structure Weight: 36.83 kDa
• Atom Count: 3,682
• Modeled Residue Count: 336
• Deposited Residue Count: 338
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Non-structural protein 3	A, B	169	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: rep, 1a-1b EC: 3.4.22
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1  Go to UniProtKB:  P0DTD1

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
A1BKI (Subject of Investigation/LOI)	D [auth A]	3-{(3R)-3-[(5-bromo-7H-pyrrolo[2,3-d]pyrimidin-4-yl)amino]butyl}-1,3-oxazolidin-2-one C13 H16 Br N5 O2 AFIGFQHYOWWULG-MRVPVSSYSA-N
DMS	C [auth A]	DIMETHYL SULFOXIDE C2 H6 O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N
CL	E [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.00 Å
• R-Value Free:  0.165 (Depositor), 0.171 (DCC)
• R-Value Work:  0.147 (Depositor), 0.157 (DCC)
• R-Value Observed: 0.148 (Depositor)

Space Group: P 4₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 88.812	α = 90
b = 88.812	β = 90
c = 39.612	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-08-20
Deposition Author(s): Correy, G.J., Fraser, J.S.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	U19AI171110

Revision History

• Version 1.0: 2025-08-20
  Type: Initial release
