8H2B | pdb_00008h2b

Crystal structure of alcohol dehydrogenase from Zobellia galactanivorans

PDB DOI: https://doi.org/10.2210/pdb8H2B/pdb

Classification: OXIDOREDUCTASE
Organism(s): Zobellia galactanivorans
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2022-10-05 Released: 2023-10-18
Deposition Author(s): Brott, S., Bornscheuer, U.T., Nam, K.H.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.205 (Depositor), 0.200 (DCC)
R-Value Work:
0.161 (Depositor), 0.160 (DCC)
R-Value Observed:
0.162 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Unique alcohol dehydrogenases involved in algal sugar utilization by marine bacteria

Brott, S., Nam, K.H., Thomas, F., Dutschei, T., Reisky, L., Behrens, M., Grimm, H.C., Michel, G., Schweder, T., Bornscheuer, U.T.

(2023) Appl Microbiol Biotechnol 107: 2363-2384

DOI: https://doi.org/10.1007/s00253-023-12447-x

Macromolecule Content

Total Structure Weight: 161.89 kDa
Atom Count: 11,683
Modeled Residue Count: 1,475
Deposited Residue Count: 1,492
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Alcohol dehydrogenase	A, B, C, D	373	Zobellia galactanivorans	Mutation(s): 0 EC: 1.1.1.1
UniProt
Find proteins for G0L712 (Zobellia galactanivorans (strain DSM 12802 / CCUG 47099 / CIP 106680 / NCIMB 13871 / Dsij)) Explore G0L712 Go to UniProtKB: G0L712
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	G0L712
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAD (Subject of Investigation/LOI) Query on NAD Download Ideal Coordinates CCD File SDF format, chain M [auth C] SDF format, chain P [auth D] SDF format, chain E [auth A] SDF format, chain I [auth B] MOL2 format, chain M [auth C] MOL2 format, chain P [auth D] MOL2 format, chain E [auth A] MOL2 format, chain I [auth B] mmCIF format, chain M [auth C] mmCIF format, chain P [auth D] mmCIF format, chain E [auth A] mmCIF format, chain I [auth B]	E [auth A], I [auth B], M [auth C], P [auth D]	NICOTINAMIDE-ADENINE-DINUCLEOTIDE C₂₁ H₂₇ N₇ O₁₄ P₂ BAWFJGJZGIEFAR-NNYOXOHSSA-N		Interactions Focus chain E [auth A] Focus chain I [auth B] Focus chain M [auth C] Focus chain P [auth D] Interactions & Density Focus chain E [auth A] Focus chain I [auth B] Focus chain M [auth C] Focus chain P [auth D]
ZN (Subject of Investigation/LOI) Query on ZN Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain N [auth C] SDF format, chain O [auth C] SDF format, chain Q [auth D] SDF format, chain R [auth D] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain N [auth C] MOL2 format, chain O [auth C] MOL2 format, chain Q [auth D] MOL2 format, chain R [auth D] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain N [auth C] mmCIF format, chain O [auth C] mmCIF format, chain Q [auth D] mmCIF format, chain R [auth D]	F [auth A] G [auth A] J [auth B] K [auth B] N [auth C] F [auth A], G [auth A], J [auth B], K [auth B], N [auth C], O [auth C], Q [auth D], R [auth D]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain Q [auth D] Focus chain R [auth D] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain Q [auth D] Focus chain R [auth D]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain L [auth B] MOL2 format, chain H [auth A] MOL2 format, chain L [auth B] mmCIF format, chain H [auth A] mmCIF format, chain L [auth B]	H [auth A], L [auth B]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain L [auth B] Interactions & Density Focus chain H [auth A] Focus chain L [auth B]
