9C1K | pdb_00009c1k

Rhesus rotavirus (empty structure at 2.68 Angstrom resolution)

PDB DOI: https://doi.org/10.2210/pdb9C1K/pdb
EM Map EMD-45122: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Simian rotavirus A strain RRV
Expression System: Simian rotavirus A strain RRV
Mutation(s): No

Deposited: 2024-05-29 Released: 2025-04-30
Deposition Author(s): Jenni, S., Herrmann, T., De Sautu, M., Harrison, S.C.
Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.68 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Rotavirus structure

Jenni, S., Herrmann, T., De Sautu, M., Harrison, S.C.

To be published.

Macromolecule Content

Total Structure Weight: 1,775.94 kDa
Atom Count: 114,366
Modeled Residue Count: 14,296
Deposited Residue Count: 15,511
Unique protein chains: 3

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Outer capsid glycoprotein VP7	A [auth 0] AA [auth Y] B [auth 1] BA [auth Z] IA [auth t] A [auth 0], AA [auth Y], B [auth 1], BA [auth Z], IA [auth t], JA [auth u], KA [auth v], LA [auth w], MA [auth x], NA [auth y], R [auth P], S [auth Q], T [auth R], U [auth S], V [auth T], W [auth U], X [auth V], Y [auth W], Z [auth X]	326	Simian rotavirus A strain RRV	Mutation(s): 0
UniProt
Find proteins for P12476 (Rotavirus A (strain RVA/Monkey/United States/RRV/1975/G3P5B[3])) Explore P12476 Go to UniProtKB: P12476
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P12476
Glycosylation
Glycosylation Sites: 1	Glycosylation Focus chain A [auth 0] Focus chain AA [auth Y] Focus chain B [auth 1] Focus chain BA [auth Z] Focus chain IA [auth t] Focus chain JA [auth u] Focus chain KA [auth v] Focus chain LA [auth w] Focus chain MA [auth x] Focus chain NA [auth y] Focus chain R [auth P] Focus chain S [auth Q] Focus chain T [auth R] Focus chain U [auth S] Focus chain V [auth T] Focus chain W [auth U] Focus chain X [auth V] Focus chain Y [auth W] Focus chain Z [auth X]
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Inner capsid protein VP2	C [auth A], D [auth B]	887	Simian rotavirus A strain RRV	Mutation(s): 0
UniProt
Find proteins for B3F2X3 (Rotavirus A (strain RVA/Monkey/United States/RRV/1975/G3P5B[3])) Explore B3F2X3 Go to UniProtKB: B3F2X3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	B3F2X3
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Intermediate capsid protein VP6	CA [auth f] DA [auth g] E [auth C] EA [auth h] F [auth D] CA [auth f], DA [auth g], E [auth C], EA [auth h], F [auth D], FA [auth i], G [auth E], GA [auth j], H [auth F], HA [auth k], I [auth G], J [auth H], K [auth I], L [auth J], M [auth K], N [auth L], O [auth M], P [auth N], Q [auth O]	397	Simian rotavirus A strain RRV	Mutation(s): 0
UniProt
Find proteins for B2BN53 (Rotavirus A (strain RVA/Monkey/United States/RRV/1975/G3P5B[3])) Explore B2BN53 Go to UniProtKB: B2BN53
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	B2BN53
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain ZC [auth V] SDF format, chain XE [auth w] SDF format, chain VB [auth P] SDF format, chain UC [auth U] SDF format, chain TD [auth Z] SDF format, chain TA [auth 1] SDF format, chain SE [auth v] SDF format, chain PC [auth T] SDF format, chain OD [auth Y] SDF format, chain OA [auth 0] SDF format, chain NE [auth u] SDF format, chain KC [auth S] SDF format, chain JD [auth X] SDF format, chain IE [auth t] SDF format, chain HF [auth y] SDF format, chain FC [auth R] SDF format, chain ED [auth W] SDF format, chain CF [auth x] SDF format, chain AC [auth Q] MOL2 format, chain ZC [auth V] MOL2 format, chain XE [auth w] MOL2 format, chain VB [auth P] MOL2 format, chain UC [auth U] MOL2 format, chain TD [auth Z] MOL2 format, chain TA [auth 1] MOL2 format, chain SE [auth v] MOL2 format, chain PC [auth T] MOL2 format, chain OD [auth Y] MOL2 format, chain OA [auth 0] MOL2 format, chain NE [auth u] MOL2 format, chain KC [auth S] MOL2 format, chain JD [auth X] MOL2 format, chain IE [auth t] MOL2 format, chain HF [auth y] MOL2 format, chain FC [auth R] MOL2 format, chain ED [auth W] MOL2 format, chain CF [auth x] MOL2 format, chain AC [auth Q] mmCIF format, chain ZC [auth V] mmCIF format, chain XE [auth w] mmCIF format, chain VB [auth P] mmCIF format, chain UC [auth U] mmCIF format, chain TD [auth Z] mmCIF format, chain TA [auth 1] mmCIF format, chain SE [auth v] mmCIF format, chain PC [auth T] mmCIF format, chain OD [auth Y] mmCIF format, chain OA [auth 0] mmCIF format, chain NE [auth u] mmCIF format, chain KC [auth S] mmCIF format, chain JD [auth X] mmCIF format, chain IE [auth t] mmCIF format, chain HF [auth y] mmCIF format, chain FC [auth R] mmCIF format, chain ED [auth W] mmCIF format, chain CF [auth x] mmCIF format, chain AC [auth Q]	AC [auth Q] CF [auth x] ED [auth W] FC [auth R] HF [auth y] AC [auth Q], CF [auth x], ED [auth W], FC [auth R], HF [auth y], IE [auth t], JD [auth X], KC [auth S], NE [auth u], OA [auth 0], OD [auth Y], PC [auth T], SE [auth v], TA [auth 1], TD [auth Z], UC [auth U], VB [auth P], XE [auth w], ZC [auth V]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AC [auth Q] Focus chain CF [auth x] Focus chain ED [auth W] Focus chain FC [auth R] Focus chain HF [auth y] Focus chain IE [auth t] Focus chain JD [auth X] Focus chain KC [auth S] Focus chain NE [auth u] Focus chain OA [auth 0] Focus chain OD [auth Y] Focus chain PC [auth T] Focus chain SE [auth v] Focus chain TA [auth 1] Focus chain TD [auth Z] Focus chain UC [auth U] Focus chain VB [auth P] Focus chain XE [auth w] Focus chain ZC [auth V] Interactions & Density Focus chain AC [auth Q] Focus chain CF [auth x] Focus chain ED [auth W] Focus chain FC [auth R] Focus chain HF [auth y] Focus chain IE [auth t] Focus chain JD [auth X] Focus chain KC [auth S] Focus chain NE [auth u] Focus chain OA [auth 0] Focus chain OD [auth Y] Focus chain PC [auth T] Focus chain SE [auth v] Focus chain TA [auth 1] Focus chain TD [auth Z] Focus chain UC [auth U] Focus chain VB [auth P] Focus chain XE [auth w] Focus chain ZC [auth V]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain YD [auth f] SDF format, chain YA [auth C] SDF format, chain UB [auth O] SDF format, chain SB [auth O] SDF format, chain RB [auth N] SDF format, chain PB [auth M] SDF format, chain OB [auth L] SDF format, chain NB [auth L] SDF format, chain MB [auth K] SDF format, chain LB [auth J] SDF format, chain KB [auth I] SDF format, chain IB [auth I] SDF format, chain HE [auth k] SDF format, chain HB [auth H] SDF format, chain GE [auth j] SDF format, chain GB [auth G] SDF format, chain FE [auth i] SDF format, chain FB [auth F] SDF format, chain DE [auth i] SDF format, chain DB [auth F] SDF format, chain CE [auth h] SDF format, chain CB [auth E] SDF format, chain BE [auth g] SDF format, chain BB [auth D] SDF format, chain AE [auth f] SDF format, chain AB [auth C] MOL2 format, chain YD [auth f] MOL2 format, chain YA [auth C] MOL2 format, chain UB [auth O] MOL2 format, chain SB [auth O] MOL2 format, chain RB [auth N] MOL2 format, chain PB [auth M] MOL2 format, chain OB [auth L] MOL2 format, chain NB [auth L] MOL2 format, chain MB [auth K] MOL2 format, chain LB [auth J] MOL2 format, chain KB [auth I] MOL2 format, chain IB [auth I] MOL2 format, chain HE [auth k] MOL2 format, chain HB [auth H] MOL2 format, chain GE [auth j] MOL2 format, chain GB [auth G] MOL2 format, chain FE [auth i] MOL2 format, chain FB [auth F] MOL2 format, chain DE [auth i] MOL2 format, chain DB [auth F] MOL2 format, chain CE [auth h] MOL2 format, chain CB [auth E] MOL2 format, chain BE [auth g] MOL2 format, chain BB [auth D] MOL2 format, chain AE [auth f] MOL2 format, chain AB [auth C] mmCIF format, chain YD [auth f] mmCIF format, chain YA [auth C] mmCIF format, chain UB [auth O] mmCIF format, chain SB [auth O] mmCIF format, chain RB [auth N] mmCIF format, chain PB [auth M] mmCIF format, chain OB [auth L] mmCIF format, chain NB [auth L] mmCIF format, chain MB [auth K] mmCIF format, chain LB [auth J] mmCIF format, chain KB [auth I] mmCIF format, chain IB [auth I] mmCIF format, chain HE [auth k] mmCIF format, chain HB [auth H] mmCIF format, chain GE [auth j] mmCIF format, chain GB [auth G] mmCIF format, chain FE [auth i] mmCIF format, chain FB [auth F] mmCIF format, chain DE [auth i] mmCIF format, chain DB [auth F] mmCIF format, chain CE [auth h] mmCIF format, chain CB [auth E] mmCIF format, chain BE [auth g] mmCIF format, chain BB [auth D] mmCIF format, chain AE [auth f] mmCIF format, chain AB [auth C]	AB [auth C] AE [auth f] BB [auth D] BE [auth g] CB [auth E] AB [auth C], AE [auth f], BB [auth D], BE [auth g], CB [auth E], CE [auth h], DB [auth F], DE [auth i], FB [auth F], FE [auth i], GB [auth G], GE [auth j], HB [auth H], HE [auth k], IB [auth I], KB [auth I], LB [auth J], MB [auth K], NB [auth L], OB [auth L], PB [auth M], RB [auth N], SB [auth O], UB [auth O], YA [auth C], YD [auth f]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain AB [auth C] Focus chain AE [auth f] Focus chain BB [auth D] Focus chain BE [auth g] Focus chain CB [auth E] Focus chain CE [auth h] Focus chain DB [auth F] Focus chain DE [auth i] Focus chain FB [auth F] Focus chain FE [auth i] Focus chain GB [auth G] Focus chain GE [auth j] Focus chain HB [auth H] Focus chain HE [auth k] Focus chain IB [auth I] Focus chain KB [auth I] Focus chain LB [auth J] Focus chain MB [auth K] Focus chain NB [auth L] Focus chain OB [auth L] Focus chain PB [auth M] Focus chain RB [auth N] Focus chain SB [auth O] Focus chain UB [auth O] Focus chain YA [auth C] Focus chain YD [auth f] Interactions & Density Focus chain AB [auth C] Focus chain AE [auth f] Focus chain BB [auth D] Focus chain BE [auth g] Focus chain CB [auth E] Focus chain CE [auth h] Focus chain DB [auth F] Focus chain DE [auth i] Focus chain FB [auth F] Focus chain FE [auth i] Focus chain GB [auth G] Focus chain GE [auth j] Focus chain HB [auth H] Focus chain HE [auth k] Focus chain IB [auth I] Focus chain KB [auth I] Focus chain LB [auth J] Focus chain MB [auth K] Focus chain NB [auth L] Focus chain OB [auth L] Focus chain PB [auth M] Focus chain RB [auth N] Focus chain SB [auth O] Focus chain UB [auth O] Focus chain YA [auth C] Focus chain YD [auth f]
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain ZE [auth w] SDF format, chain ZB [auth P] SDF format, chain YE [auth w] SDF format, chain YC [auth U] SDF format, chain YB [auth P] SDF format, chain XD [auth Z] SDF format, chain XC [auth U] SDF format, chain XB [auth P] SDF format, chain XA [auth 1] SDF format, chain WE [auth v] SDF format, chain WD [auth Z] SDF format, chain WC [auth U] SDF format, chain WB [auth P] SDF format, chain WA [auth 1] SDF format, chain VE [auth v] SDF format, chain VD [auth Z] SDF format, chain VC [auth U] SDF format, chain VA [auth 1] SDF format, chain UE [auth v] SDF format, chain UD [auth Z] SDF format, chain UA [auth 1] SDF format, chain TE [auth v] SDF format, chain TC [auth T] SDF format, chain SD [auth Y] SDF format, chain SC [auth T] SDF format, chain SA [auth 0] SDF format, chain RE [auth u] SDF format, chain RD [auth Y] SDF format, chain RC [auth T] SDF format, chain RA [auth 0] SDF format, chain QE [auth u] SDF format, chain QD [auth Y] SDF format, chain QC [auth T] SDF format, chain QA [auth 0] SDF format, chain PE [auth u] SDF format, chain PD [auth Y] SDF format, chain PA [auth 0] SDF format, chain OE [auth u] SDF format, chain OC [auth S] SDF format, chain ND [auth X] SDF format, chain NC [auth S] SDF format, chain ME [auth t] SDF format, chain MD [auth X] SDF format, chain MC [auth S] SDF format, chain LF [auth y] SDF format, chain LE [auth t] SDF format, chain LD [auth X] SDF format, chain LC [auth S] SDF format, chain KF [auth y] SDF format, chain KE [auth t] SDF format, chain KD [auth X] SDF format, chain JF [auth y] SDF format, chain JE [auth t] SDF format, chain JC [auth R] SDF format, chain IF [auth y] SDF format, chain ID [auth W] SDF format, chain IC [auth R] SDF format, chain HD [auth W] SDF format, chain HC [auth R] SDF format, chain GF [auth x] SDF format, chain GD [auth W] SDF format, chain GC [auth R] SDF format, chain FF [auth x] SDF format, chain FD [auth W] SDF format, chain EF [auth x] SDF format, chain EC [auth Q] SDF format, chain DF [auth x] SDF format, chain DD [auth V] SDF format, chain DC [auth Q] SDF format, chain CD [auth V] SDF format, chain CC [auth Q] SDF format, chain BF [auth w] SDF format, chain BD [auth V] SDF format, chain BC [auth Q] SDF format, chain AF [auth w] SDF format, chain AD [auth V] MOL2 format, chain ZE [auth w] MOL2 format, chain ZB [auth P] MOL2 format, chain YE [auth w] MOL2 format, chain YC [auth U] MOL2 format, chain YB [auth P] MOL2 format, chain XD [auth Z] MOL2 format, chain XC [auth U] MOL2 format, chain XB [auth P] MOL2 format, chain XA [auth 1] MOL2 format, chain WE [auth v] MOL2 format, chain WD [auth Z] MOL2 format, chain WC [auth U] MOL2 format, chain WB [auth P] MOL2 format, chain WA [auth 1] MOL2 format, chain VE [auth v] MOL2 format, chain VD [auth Z] MOL2 format, chain VC [auth U] MOL2 format, chain VA [auth 1] MOL2 format, chain UE [auth v] MOL2 format, chain UD [auth Z] MOL2 format, chain UA [auth 1] MOL2 format, chain TE [auth v] MOL2 format, chain TC [auth T] MOL2 format, chain SD [auth Y] MOL2 format, chain SC [auth T] MOL2 format, chain SA [auth 0] MOL2 format, chain RE [auth u] MOL2 format, chain RD [auth Y] MOL2 format, chain RC [auth T] MOL2 format, chain RA [auth 0] MOL2 format, chain QE [auth u] MOL2 format, chain QD [auth Y] MOL2 format, chain QC [auth T] MOL2 format, chain QA [auth 0] MOL2 format, chain PE [auth u] MOL2 format, chain PD [auth Y] MOL2 format, chain PA [auth 0] MOL2 format, chain OE [auth u] MOL2 format, chain OC [auth S] MOL2 format, chain ND [auth X] MOL2 format, chain NC [auth S] MOL2 format, chain ME [auth t] MOL2 format, chain MD [auth X] MOL2 format, chain MC [auth S] MOL2 format, chain LF [auth y] MOL2 format, chain LE [auth t] MOL2 format, chain LD [auth X] MOL2 format, chain LC [auth S] MOL2 format, chain KF [auth y] MOL2 format, chain KE [auth t] MOL2 format, chain KD [auth X] MOL2 format, chain JF [auth y] MOL2 format, chain JE [auth t] MOL2 format, chain JC [auth R] MOL2 format, chain IF [auth y] MOL2 format, chain ID [auth W] MOL2 format, chain IC [auth R] MOL2 format, chain HD [auth W] MOL2 format, chain HC [auth R] MOL2 format, chain GF [auth x] MOL2 format, chain GD [auth W] MOL2 format, chain GC [auth R] MOL2 format, chain FF [auth x] MOL2 format, chain FD [auth W] MOL2 format, chain EF [auth x] MOL2 format, chain EC [auth Q] MOL2 format, chain DF [auth x] MOL2 format, chain DD [auth V] MOL2 format, chain DC [auth Q] MOL2 format, chain CD [auth V] MOL2 format, chain CC [auth Q] MOL2 format, chain BF [auth w] MOL2 format, chain BD [auth V] MOL2 format, chain BC [auth Q] MOL2 format, chain AF [auth w] MOL2 format, chain AD [auth V] mmCIF format, chain ZE [auth w] mmCIF format, chain ZB [auth P] mmCIF format, chain YE [auth w] mmCIF format, chain YC [auth U] mmCIF format, chain YB [auth P] mmCIF format, chain XD [auth Z] mmCIF format, chain XC [auth U] mmCIF format, chain XB [auth P] mmCIF format, chain XA [auth 1] mmCIF format, chain WE [auth v] mmCIF format, chain WD [auth Z] mmCIF format, chain WC [auth U] mmCIF format, chain WB [auth P] mmCIF format, chain WA [auth 1] mmCIF format, chain VE [auth v] mmCIF format, chain VD [auth Z] mmCIF format, chain VC [auth U] mmCIF format, chain VA [auth 1] mmCIF format, chain UE [auth v] mmCIF format, chain UD [auth Z] mmCIF format, chain UA [auth 1] mmCIF format, chain TE [auth v] mmCIF format, chain TC [auth T] mmCIF format, chain SD [auth Y] mmCIF format, chain SC [auth T] mmCIF format, chain SA [auth 0] mmCIF format, chain RE [auth u] mmCIF format, chain RD [auth Y] mmCIF format, chain RC [auth T] mmCIF format, chain RA [auth 0] mmCIF format, chain QE [auth u] mmCIF format, chain QD [auth Y] mmCIF format, chain QC [auth T] mmCIF format, chain QA [auth 0] mmCIF format, chain PE [auth u] mmCIF format, chain PD [auth Y] mmCIF format, chain PA [auth 0] mmCIF format, chain OE [auth u] mmCIF format, chain OC [auth S] mmCIF format, chain ND [auth X] mmCIF format, chain NC [auth S] mmCIF format, chain ME [auth t] mmCIF format, chain MD [auth X] mmCIF format, chain MC [auth S] mmCIF format, chain LF [auth y] mmCIF format, chain LE [auth t] mmCIF format, chain LD [auth X] mmCIF format, chain LC [auth S] mmCIF format, chain KF [auth y] mmCIF format, chain KE [auth t] mmCIF format, chain KD [auth X] mmCIF format, chain JF [auth y] mmCIF format, chain JE [auth t] mmCIF format, chain JC [auth R] mmCIF format, chain IF [auth y] mmCIF format, chain ID [auth W] mmCIF format, chain IC [auth R] mmCIF format, chain HD [auth W] mmCIF format, chain HC [auth R] mmCIF format, chain GF [auth x] mmCIF format, chain GD [auth W] mmCIF format, chain GC [auth R] mmCIF format, chain FF [auth x] mmCIF format, chain FD [auth W] mmCIF format, chain EF [auth x] mmCIF format, chain EC [auth Q] mmCIF format, chain DF [auth x] mmCIF format, chain DD [auth V] mmCIF format, chain DC [auth Q] mmCIF format, chain CD [auth V] mmCIF format, chain CC [auth Q] mmCIF format, chain BF [auth w] mmCIF format, chain BD [auth V] mmCIF format, chain BC [auth Q] mmCIF format, chain AF [auth w] mmCIF format, chain AD [auth V]	AD [auth V] AF [auth w] BC [auth Q] BD [auth V] BF [auth w] AD [auth V], AF [auth w], BC [auth Q], BD [auth V], BF [auth w], CC [auth Q], CD [auth V], DC [auth Q], DD [auth V], DF [auth x], EC [auth Q], EF [auth x], FD [auth W], FF [auth x], GC [auth R], GD [auth W], GF [auth x], HC [auth R], HD [auth W], IC [auth R], ID [auth W], IF [auth y], JC [auth R], JE [auth t], JF [auth y], KD [auth X], KE [auth t], KF [auth y], LC [auth S], LD [auth X], LE [auth t], LF [auth y], MC [auth S], MD [auth X], ME [auth t], NC [auth S], ND [auth X], OC [auth S], OE [auth u], PA [auth 0], PD [auth Y], PE [auth u], QA [auth 0], QC [auth T], QD [auth Y], QE [auth u], RA [auth 0], RC [auth T], RD [auth Y], RE [auth u], SA [auth 0], SC [auth T], SD [auth Y], TC [auth T], TE [auth v], UA [auth 1], UD [auth Z], UE [auth v], VA [auth 1], VC [auth U], VD [auth Z], VE [auth v], WA [auth 1], WB [auth P], WC [auth U], WD [auth Z], WE [auth v], XA [auth 1], XB [auth P], XC [auth U], XD [auth Z], YB [auth P], YC [auth U], YE [auth w], ZB [auth P], ZE [auth w]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain AD [auth V] Focus chain AF [auth w] Focus chain BC [auth Q] Focus chain BD [auth V] Focus chain BF [auth w] Focus chain CC [auth Q] Focus chain CD [auth V] Focus chain DC [auth Q] Focus chain DD [auth V] Focus chain DF [auth x] Focus chain EC [auth Q] Focus chain EF [auth x] Focus chain FD [auth W] Focus chain FF [auth x] Focus chain GC [auth R] Focus chain GD [auth W] Focus chain GF [auth x] Focus chain HC [auth R] Focus chain HD [auth W] Focus chain IC [auth R] Focus chain ID [auth W] Focus chain IF [auth y] Focus chain JC [auth R] Focus chain JE [auth t] Focus chain JF [auth y] Focus chain KD [auth X] Focus chain KE [auth t] Focus chain KF [auth y] Focus chain LC [auth S] Focus chain LD [auth X] Focus chain LE [auth t] Focus chain LF [auth y] Focus chain MC [auth S] Focus chain MD [auth X] Focus chain ME [auth t] Focus chain NC [auth S] Focus chain ND [auth X] Focus chain OC [auth S] Focus chain OE [auth u] Focus chain PA [auth 0] Focus chain PD [auth Y] Focus chain PE [auth u] Focus chain QA [auth 0] Focus chain QC [auth T] Focus chain QD [auth Y] Focus chain QE [auth u] Focus chain RA [auth 0] Focus chain RC [auth T] Focus chain RD [auth Y] Focus chain RE [auth u] Focus chain SA [auth 0] Focus chain SC [auth T] Focus chain SD [auth Y] Focus chain TC [auth T] Focus chain TE [auth v] Focus chain UA [auth 1] Focus chain UD [auth Z] Focus chain UE [auth v] Focus chain VA [auth 1] Focus chain VC [auth U] Focus chain VD [auth Z] Focus chain VE [auth v] Focus chain WA [auth 1] Focus chain WB [auth P] Focus chain WC [auth U] Focus chain WD [auth Z] Focus chain WE [auth v] Focus chain XA [auth 1] Focus chain XB [auth P] Focus chain XC [auth U] Focus chain XD [auth Z] Focus chain YB [auth P] Focus chain YC [auth U] Focus chain YE [auth w] Focus chain ZB [auth P] Focus chain ZE [auth w] Interactions & Density Focus chain AD [auth V] Focus chain AF [auth w] Focus chain BC [auth Q] Focus chain BD [auth V] Focus chain BF [auth w] Focus chain CC [auth Q] Focus chain CD [auth V] Focus chain DC [auth Q] Focus chain DD [auth V] Focus chain DF [auth x] Focus chain EC [auth Q] Focus chain EF [auth x] Focus chain FD [auth W] Focus chain FF [auth x] Focus chain GC [auth R] Focus chain GD [auth W] Focus chain GF [auth x] Focus chain HC [auth R] Focus chain HD [auth W] Focus chain IC [auth R] Focus chain ID [auth W] Focus chain IF [auth y] Focus chain JC [auth R] Focus chain JE [auth t] Focus chain JF [auth y] Focus chain KD [auth X] Focus chain KE [auth t] Focus chain KF [auth y] Focus chain LC [auth S] Focus chain LD [auth X] Focus chain LE [auth t] Focus chain LF [auth y] Focus chain MC [auth S] Focus chain MD [auth X] Focus chain ME [auth t] Focus chain NC [auth S] Focus chain ND [auth X] Focus chain OC [auth S] Focus chain OE [auth u] Focus chain PA [auth 0] Focus chain PD [auth Y] Focus chain PE [auth u] Focus chain QA [auth 0] Focus chain QC [auth T] Focus chain QD [auth Y] Focus chain QE [auth u] Focus chain RA [auth 0] Focus chain RC [auth T] Focus chain RD [auth Y] Focus chain RE [auth u] Focus chain SA [auth 0] Focus chain SC [auth T] Focus chain SD [auth Y] Focus chain TC [auth T] Focus chain TE [auth v] Focus chain UA [auth 1] Focus chain UD [auth Z] Focus chain UE [auth v] Focus chain VA [auth 1] Focus chain VC [auth U] Focus chain VD [auth Z] Focus chain VE [auth v] Focus chain WA [auth 1] Focus chain WB [auth P] Focus chain WC [auth U] Focus chain WD [auth Z] Focus chain WE [auth v] Focus chain XA [auth 1] Focus chain XB [auth P] Focus chain XC [auth U] Focus chain XD [auth Z] Focus chain YB [auth P] Focus chain YC [auth U] Focus chain YE [auth w] Focus chain ZB [auth P] Focus chain ZE [auth w]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain ZD [auth f] SDF format, chain ZA [auth C] SDF format, chain TB [auth O] SDF format, chain QB [auth N] SDF format, chain JB [auth I] SDF format, chain EE [auth i] SDF format, chain EB [auth F] MOL2 format, chain ZD [auth f] MOL2 format, chain ZA [auth C] MOL2 format, chain TB [auth O] MOL2 format, chain QB [auth N] MOL2 format, chain JB [auth I] MOL2 format, chain EE [auth i] MOL2 format, chain EB [auth F] mmCIF format, chain ZD [auth f] mmCIF format, chain ZA [auth C] mmCIF format, chain TB [auth O] mmCIF format, chain QB [auth N] mmCIF format, chain JB [auth I] mmCIF format, chain EE [auth i] mmCIF format, chain EB [auth F]	EB [auth F] EE [auth i] JB [auth I] QB [auth N] TB [auth O] EB [auth F], EE [auth i], JB [auth I], QB [auth N], TB [auth O], ZA [auth C], ZD [auth f]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain EB [auth F] Focus chain EE [auth i] Focus chain JB [auth I] Focus chain QB [auth N] Focus chain TB [auth O] Focus chain ZA [auth C] Focus chain ZD [auth f] Interactions & Density Focus chain EB [auth F] Focus chain EE [auth i] Focus chain JB [auth I] Focus chain QB [auth N] Focus chain TB [auth O] Focus chain ZA [auth C] Focus chain ZD [auth f]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
FME Query on FME	CA [auth f] DA [auth g] E [auth C] EA [auth h] F [auth D] CA [auth f], DA [auth g], E [auth C], EA [auth h], F [auth D], FA [auth i], G [auth E], GA [auth j], H [auth F], HA [auth k], I [auth G], J [auth H], K [auth I], L [auth J], M [auth K], N [auth L], O [auth M], P [auth N], Q [auth O]	L-PEPTIDE LINKING	C₆ H₁₁ N O₃ S		MET
