9DVH | pdb_00009dvh

A1 Tei + D-Hpg: Adenylation Domain 1 Core Construct from Teicoplanin Biosynthesis with D-4-Hydroxyphenylglycine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.66 Å
  • R-Value Free:
    0.192 (Depositor), 0.191 (DCC)
  • R-Value Work:
    0.168 (Depositor), 0.167 (DCC)
  • R-Value Observed:
    0.170 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Teicoplanin Nonribosomal Peptide Synthetase Is Unable to Incorporate Alpha-Ketoacid Building Blocks.

Ratnayake, M.S.Jian, X.Tailhades, J.Challis, G.L.Hansen, M.H.Lewandowski, J.R.Cryle, M.J.

(2025) Biochemistry 64: 2039-2053

  • DOI: https://doi.org/10.1021/acs.biochem.4c00770
  • Primary Citation of Related Structures:
    9DVH

  • PubMed Abstract:

    Glycopeptide antibiotics (GPAs) are a vital class of nonribosomal peptides used as therapies of last resort to treat infections by multidrug-resistant bacteria. These peptide antibiotics are assembled by nonribosomal peptide synthetases (NRPSs), modular megasynthases central to the biosynthesis of a wide range of peptide natural products. The adenylation (A) domains of NRPSs are involved in the selection and activation of the amino acid building blocks forming these peptide natural products, with their subsequent loading onto a neighboring carrier protein for incorporation into the growing peptide chain. This makes A-domains the gatekeepers of specificity in nonribosomal peptide biosynthesis, with further studies needed to reveal how this specificity is enforced at all stages of catalysis. The first building block found in GPAs is diverse and can comprise an amino acid, a ketoacid, or mixtures of both, which suggests that the A-domains responsible for selecting these residues can also incorporate non-amino acid substrates. In this study, we explored the acceptance of such substrates by the initiation module of the teicoplanin NRPS. Our in vitro assays demonstrated that this A-domain possesses an unexpected preference for activating ketoacids over the native amino acid substrate l-Hpg. However, only (d/l)-Hpg and related amino acids were able to be loaded onto the neighboring carrier protein domain during the subsequent thioesterification step. We further characterized the structure of this A-domain from teicoplanin biosynthesis in complex with d-4-hydroxyphenylglycine (d-Hpg), which revealed alterations in the positioning of the substrate carboxylate that help explain the high levels of pyrophosphate release seen with this amino acid. In combination with extensive molecular dynamics simulations, these data suggest that ketoacid incorporation in GPA biosynthesis is likely performed after amino acid incorporation by the NRPS and highlight the importance of considering both activation and carrier protein loading reactions performed by an A-domain when investigating substrate selectivity in nonribosomal peptide biosynthesis.


  • Organizational Affiliation
    • Biomedicine Discovery Institute, Department of Biochemistry and Molecular Biology, Monash University, Clayton 3800, Australia.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Non-ribosomal peptide synthetase
A, B
399Actinoplanes teichomyceticusMutation(s): 0
Gene Names: tcp9
UniProt
Find proteins for Q70AZ9 (Actinoplanes teichomyceticus)
Explore Q70AZ9
Go to UniProtKB:  Q70AZ9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ70AZ9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
MbtH-like short polypeptide
C, D
69Actinoplanes teichomyceticusMutation(s): 0
Gene Names: tcp13
UniProt
Find proteins for Q6ZZJ2 (Actinoplanes teichomyceticus)
Explore Q6ZZJ2
Go to UniProtKB:  Q6ZZJ2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6ZZJ2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MES
Query on MES

Download Ideal Coordinates CCD File
H [auth B]2-(N-MORPHOLINO)-ETHANESULFONIC ACID
C6 H13 N O4 S
SXGZJKUKBWWHRA-UHFFFAOYSA-N
GHP (Subject of Investigation/LOI)
Query on GHP

Download Ideal Coordinates CCD File
E [auth A],
F [auth A],
G [auth B],
I [auth B]
(2R)-amino(4-hydroxyphenyl)ethanoic acid
C8 H9 N O3
LJCWONGJFPCTTL-SSDOTTSWSA-N
BO3
Query on BO3

Download Ideal Coordinates CCD File
J [auth B]BORIC ACID
B H3 O3
KGBXLFKZBHKPEV-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.66 Å
  • R-Value Free:  0.192 (Depositor), 0.191 (DCC)
  • R-Value Work:  0.168 (Depositor), 0.167 (DCC)
  • R-Value Observed: 0.170 (Depositor)
Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.253α = 90
b = 123.488β = 90
c = 176.067γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Australian Research Council (ARC)AustraliaDP190101272
Australian Research Council (ARC)AustraliaDP210101752

Revision History  (Full details and data files)

  • Version 1.0: 2025-08-13
    Type: Initial release
