9FIX | pdb_00009fix

MU2 ADAPTIN SUBUNIT (AP50) OF AP2 ADAPTOR (SECOND DOMAIN), COMPLEXED WITH LRP6 INTERNALIZATION PEPTIDE SYRPYSYRHFA

PDB DOI: https://doi.org/10.2210/pdb9FIX/pdb

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens, Rattus norvegicus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-05-29 Released: 2025-04-23
Deposition Author(s): Renko, M., Gammons, M.V., Bienz, M.
Funding Organization(s): Medical Research Council (MRC, United Kingdom)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.78 Å
R-Value Free:
0.233 (Depositor), 0.233 (DCC)
R-Value Work:
0.197 (Depositor), 0.207 (DCC)
R-Value Observed:
0.198 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

MU2 ADAPTIN SUBUNIT (AP50) OF AP2 ADAPTOR (SECOND DOMAIN), COMPLEXED WITH LRP6 INTERNALIZATION PEPTIDE SYRPYSYRHFA

Gammons, M.V.

To be published.

Macromolecule Content

Total Structure Weight: 34.34 kDa
Atom Count: 2,089
Modeled Residue Count: 260
Deposited Residue Count: 297
Unique protein chains: 2

Macromolecules

Find similar proteins by: Sequence | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Low-density lipoprotein receptor-related protein 6	A	11	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for O75581 (Homo sapiens) Explore O75581 Go to UniProtKB: O75581
PHAROS: O75581 GTEx: ENSG00000070018
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O75581
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
AP-2 complex subunit mu	B [auth M]	286	Rattus norvegicus	Mutation(s): 0 Gene Names: Ap2m1
UniProt
Find proteins for P84092 (Rattus norvegicus) Explore P84092 Go to UniProtKB: P84092
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P84092
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.78 Å
R-Value Free: 0.233 (Depositor), 0.233 (DCC)
R-Value Work: 0.197 (Depositor), 0.207 (DCC)
R-Value Observed: 0.198 (Depositor)

Space Group: P 6₄

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 125.796	α = 90
b = 125.796	β = 90
c = 73.766	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
xia2	data reduction
Aimless	data scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-04-23

Deposition Author(s):

Funding Organization	Location	Grant Number
Medical Research Council (MRC, United Kingdom)	United Kingdom	--

Revision History (Full details and data files)

Version 1.0: 2025-04-23
Type: Initial release
