9FQC | pdb_00009fqc

Crystal structure of phosphoserine phosphatase (SerB) from Brucella melitensis in copmplex with O-Phosphoserine

• PDB DOI: https://doi.org/10.2210/pdb9FQC/pdb

• Classification: HYDROLASE
• Organism(s): Brucella melitensis
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2024-06-15 Released: 2025-06-25
• Deposition Author(s): Scaillet, T., Wouters, J.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.35 Å
• R-Value Free:
  0.193 (Depositor), 0.194 (DCC)
• R-Value Work:
  0.160 (Depositor), 0.162 (DCC)
• R-Value Observed:
  0.161 (Depositor)

Starting Model: experimental

Literature

Crystal structure of phosphoserine phosphatase (SerB) from Brucella melitensis in copmplex with O-Phosphoserine

Scaillet, T., Wouters, J.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: SAXS

Macromolecule Content

• Total Structure Weight: 32.94 kDa
• Atom Count: 2,391
• Modeled Residue Count: 295
• Deposited Residue Count: 307
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphoserine phosphatase	A	307	Brucella melitensis	Mutation(s): 0  Gene Names: BMEI0615 EC: 3.1.3.3
UniProt
Find proteins for Q8YI30 (Brucella melitensis biotype 1 (strain ATCC 23456 / CCUG 17765 / NCTC 10094 / 16M)) Explore Q8YI30  Go to UniProtKB:  Q8YI30

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SEP (Subject of Investigation/LOI)	B [auth A]	PHOSPHOSERINE C3 H8 N O6 P BZQFBWGGLXLEPQ-REOHCLBHSA-N
GOL	C [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
CA	D [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N
CL	E [auth A], F [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.35 Å
• R-Value Free:  0.193 (Depositor), 0.194 (DCC)
• R-Value Work:  0.160 (Depositor), 0.162 (DCC)
• R-Value Observed: 0.161 (Depositor)

Space Group: I 2₁ 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 145.25	α = 90
b = 145.25	β = 90
c = 145.25	γ = 90

Software Package:

Software Name	Purpose
MxCuBE	data collection
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing
Coot	model building

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-06-25
Deposition Author(s): Scaillet, T., Wouters, J.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2025-06-25
  Type: Initial release
