9MGR | pdb_00009mgr

Crystal structure of PRMT5:MEP50 in complex with MTA and compound 51

PDB DOI: https://doi.org/10.2210/pdb9MGR/pdb

Classification: TRANSFERASE/INHIBITOR
Organism(s): Homo sapiens
Expression System: Trichoplusia ni
Mutation(s): No

Deposited: 2024-12-11 Released: 2025-03-05
Deposition Author(s): Whittington, D.A.
Funding Organization(s): Other private

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.07 Å
R-Value Free:
0.273 (Depositor), 0.271 (DCC)
R-Value Work:
0.222 (Depositor), 0.227 (DCC)
R-Value Observed:
0.224 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

MTA-Cooperative PRMT5 Inhibitors: Mechanism Switching Through Structure-Based Design.

Cottrell, K.M., Whittington, D.A., Briggs, K.J., Jahic, H., Ali, J.A., Amor, A.J., Gotur, D., Tonini, M.R., Zhang, W., Huang, A., Maxwell, J.P.

(2025) J Med Chem 68: 4217-4236

PubMed: 39919252 Search on PubMedSearch on PubMed Central
DOI: https://doi.org/10.1021/acs.jmedchem.4c01998
Primary Citation of Related Structures:
9MGL, 9MGM, 9MGN, 9MGP, 9MGQ, 9MGR

PubMed Abstract:
Deletion of the MTAP gene leads to accumulation of the substrate of the MTAP protein, methylthioadenosine (MTA). MTA binds PRMT5 competitively with S-adenosyl-l-methionine (SAM), and selective inhibition of the PRMT5•MTA complex relative to the PRMT5•SAM complex can lead to selective killing of cancer cells with MTAP deletion. Herein, we describe the discovery of novel compounds using structure-based drug design to switch the mechanism of binding of known, SAM-cooperative PRMT5 inhibitors to an MTA-cooperative binding mechanism by occupying the portion of the SAM binding pocket in PRMT5 that is unoccupied when MTA is bound and hydrogen bonding to Arg368, thereby allowing them to selectively target MTAP -deleted cancer cells.

Organizational Affiliation

Tango Therapeutics, 201 Brookline Ave, Boston, Massachusetts 02215, United States.

Macromolecule Content

Total Structure Weight: 113.47 kDa
Atom Count: 7,720
Modeled Residue Count: 922
Deposited Residue Count: 995
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein arginine N-methyltransferase 5	A	645	Homo sapiens	Mutation(s): 0 Gene Names: PRMT5, HRMT1L5, IBP72, JBP1, SKB1 EC: 2.1.1.320
UniProt & NIH Common Fund Data Resources
Find proteins for O14744 (Homo sapiens) Explore O14744 Go to UniProtKB: O14744
PHAROS: O14744 GTEx: ENSG00000100462
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O14744
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Methylosome protein 50	B	350	Homo sapiens	Mutation(s): 0 Gene Names: WDR77, MEP50, WD45, HKMT1069, Nbla10071
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BQA1 (Homo sapiens) Explore Q9BQA1 Go to UniProtKB: Q9BQA1
PHAROS: Q9BQA1 GTEx: ENSG00000116455
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9BQA1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1BLF (Subject of Investigation/LOI) Query on A1BLF Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	6-[(1-acetylazetidin-3-yl)amino]-N-[(2R)-2-hydroxy-2-{(3S)-7-[(4-methyl-1,3-oxazol-5-yl)methoxy]-1,2,3,4-tetrahydroisoquinolin-3-yl}ethyl]-2-(4-methylpiperidin-1-yl)pyrimidine-4-carboxamide C₃₂ H₄₂ N₈ O₅ YORKMGQSIAFLDS-XTEPFMGCSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
MTA Query on MTA Download Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	5'-DEOXY-5'-METHYLTHIOADENOSINE C₁₁ H₁₅ N₅ O₃ S WUUGFSXJNOTRMR-IOSLPCCCSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain S [auth B] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain S [auth B] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A] mmCIF format, chain Q [auth A] mmCIF format, chain R [auth A] mmCIF format, chain S [auth B]	E [auth A] F [auth A] G [auth A] H [auth A] I [auth A] E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], Q [auth A], R [auth A], S [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth B]
