1VQO

The structure of CCPMN bound to the large ribosomal subunit haloarcula marismortui


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.215

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural Insights into the Roles of Water and the 2' Hydroxyl of the P Site tRNA in the Peptidyl Transferase Reaction.

Schmeing, T.M.Huang, K.S.Kitchen, D.E.Strobel, S.A.Steitz, T.A.

(2005) Mol Cell 20: 437-448

  • DOI: 10.1016/j.molcel.2005.09.006
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Peptide bond formation is catalyzed at the peptidyl transferase center (PTC) of the large ribosomal subunit. Crystal structures of the large ribosomal subunit of Haloarcula marismortui (Hma) complexed with several analogs that represent either the su ...

    Peptide bond formation is catalyzed at the peptidyl transferase center (PTC) of the large ribosomal subunit. Crystal structures of the large ribosomal subunit of Haloarcula marismortui (Hma) complexed with several analogs that represent either the substrates or the transition state intermediate of the peptidyl transferase reaction show that this reaction proceeds through a tetrahedral intermediate with S chirality. The oxyanion of the tetrahedral intermediate interacts with a water molecule that is positioned by nucleotides A2637 (E. coli numbering, 2602) and (methyl)U2619(2584). There are no Mg2+ ions or monovalent metal ions observed in the PTC that could directly promote catalysis. The A76 2' hydroxyl of the peptidyl-tRNA is hydrogen bonded to the alpha-amino group and could facilitate peptide bond formation by substrate positioning and by acting as a proton shuttle between the alpha-amino group and the A76 3' hydroxyl of the peptidyl-tRNA.


    Organizational Affiliation

    Department of Molecular Biophysics and Biochemistry, Yale University, New Haven, Connecticut 06520, USA.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L2P
A
240Haloarcula marismortuiMutation(s): 0
Find proteins for P20276 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P20276

Find similar proteins by: Sequence  |  Structure

Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L3P
B
338Haloarcula marismortuiMutation(s): 0
Find proteins for P20279 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P20279

Find similar proteins by: Sequence  |  Structure

Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L4E
C
246Haloarcula marismortuiMutation(s): 0
Find proteins for P12735 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P12735

Find similar proteins by: Sequence  |  Structure

Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L5P
D
177Haloarcula marismortuiMutation(s): 0
Find proteins for P14124 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P14124

Find similar proteins by: Sequence  |  Structure

Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L7AE
F
120Haloarcula marismortuiMutation(s): 0
Find proteins for P12743 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P12743

Find similar proteins by: Sequence  |  Structure

Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
ACIDIC RIBOSOMAL PROTEIN P0 HOMOLOG
G
348Haloarcula marismortuiMutation(s): 0
Find proteins for P15825 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P15825

Find similar proteins by: Sequence  |  Structure

Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
50S RIBOSOMAL PROTEIN L10E
H
171Haloarcula marismortuiMutation(s): 0
Find proteins for P60617 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P60617

Find similar proteins by: Sequence  |  Structure

Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L13P
J
145Haloarcula marismortuiMutation(s): 0
Find proteins for P29198 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P29198

Find similar proteins by: Sequence  |  Structure

Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L14P
K
132Haloarcula marismortuiMutation(s): 0
Find proteins for P22450 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P22450

Find similar proteins by: Sequence  |  Structure

Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L15P
L
165Haloarcula marismortuiMutation(s): 0
Find proteins for P12737 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P12737

Find similar proteins by: Sequence  |  Structure

Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L18P
N
187Haloarcula marismortuiMutation(s): 0
Find proteins for P14123 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P14123

Find similar proteins by: Sequence  |  Structure

Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L18e
O
116Haloarcula marismortuiMutation(s): 0
Find proteins for P12733 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P12733

Find similar proteins by: Sequence  |  Structure

Entity ID: 18
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L19E
P
149Haloarcula marismortuiMutation(s): 0
Find proteins for P14119 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P14119

Find similar proteins by: Sequence  |  Structure

Entity ID: 19
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L21e
Q
96Haloarcula marismortuiMutation(s): 0
Find proteins for P12734 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P12734

Find similar proteins by: Sequence  |  Structure

Entity ID: 20
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L22P
R
155Haloarcula marismortuiMutation(s): 0
Find proteins for P10970 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P10970

Find similar proteins by: Sequence  |  Structure

Entity ID: 21
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L23P
S
85Haloarcula marismortuiMutation(s): 0
Find proteins for P12732 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P12732

Find similar proteins by: Sequence  |  Structure

Entity ID: 22
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L24P
T
120Haloarcula marismortuiMutation(s): 0
Find proteins for P10972 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P10972

Find similar proteins by: Sequence  |  Structure

Entity ID: 23
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L24E
U
66Haloarcula marismortuiMutation(s): 0
Find proteins for P14116 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P14116

Find similar proteins by: Sequence  |  Structure

Entity ID: 24
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L29P
V
71Haloarcula marismortuiMutation(s): 0
Find proteins for P10971 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P10971

Find similar proteins by: Sequence  |  Structure

Entity ID: 25
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L30P
W
154Haloarcula marismortuiMutation(s): 0
Find proteins for P14121 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P14121

Find similar proteins by: Sequence  |  Structure

Entity ID: 26
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L31e
X
92Haloarcula marismortuiMutation(s): 0
Find proteins for P18138 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P18138

Find similar proteins by: Sequence  |  Structure

Entity ID: 27
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L32E
Y
241Haloarcula marismortuiMutation(s): 0
Find proteins for P12736 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P12736

Find similar proteins by: Sequence  |  Structure

Entity ID: 28
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L37Ae
Z
83Haloarcula marismortuiMutation(s): 0
Find proteins for P60619 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P60619

Find similar proteins by: Sequence  |  Structure

Entity ID: 29
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L37e
1
57Haloarcula marismortuiMutation(s): 0
Find proteins for P32410 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P32410

Find similar proteins by: Sequence  |  Structure

Entity ID: 31
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L44E
3
92Haloarcula marismortuiMutation(s): 0
Find proteins for P32411 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P32411

Find similar proteins by: Sequence  |  Structure

Entity ID: 32
MoleculeChainsSequence LengthOrganismDetails
50S RIBOSOMAL PROTEIN L11P
I
162Haloarcula marismortuiMutation(s): 0
Find proteins for P14122 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P14122

Find similar proteins by: Sequence  |  Structure

Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
50S Ribosomal Protein L15E
M
195Haloarcula marismortuiMutation(s): 0
Find proteins for P60618 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P60618

Find similar proteins by: Sequence  |  Structure

Entity ID: 30
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L39e
2
50Haloarcula marismortuiMutation(s): 0
Find proteins for P22452 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P22452

Find similar proteins by: Sequence  |  Structure

Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L6P
E
178Haloarcula marismortuiMutation(s): 0
Find proteins for P14135 (Haloarcula marismortui (strain ATCC 43049 / DSM 3752 / JCM 8966 / VKM B-1809))
Go to UniProtKB:  P14135

Find similar nucleic acids by: Sequence   |  Structure

Entity ID: 1
MoleculeChainsLengthOrganism
23S ribosomal rna02922Haloarcula marismortui

Find similar nucleic acids by: Sequence   |  Structure

Entity ID: 2
MoleculeChainsLengthOrganism
5S ribosomal RNA9122Haloarcula marismortui
  • Find similar nucleic acids by: Sequence   |   Structure
Entity ID: 3
MoleculeChainsLengthOrganism
5'-R(*CP*CP*(PPU))-3'43N/A
Small Molecules
Ligands 6 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CD
Query on CD

Download CCD File
1, 3, O, U, Z
CADMIUM ION
Cd
WLZRMCYVCSSEQC-UHFFFAOYSA-N
 Ligand Interaction
SR
Query on SR

Download CCD File
0, 1, 3, 9, A, B, F, H, L, R, S
STRONTIUM ION
Sr
PWYYWQHXAPXYMF-UHFFFAOYSA-N
 Ligand Interaction
K
Query on K

Download CCD File
0
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download CCD File
0, 3, A, B, J, K, L, M, N, O, R, Y
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
MG
Query on MG

Download CCD File
0, 9, A, B, K, T, Y
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
NA
Query on NA

Download CCD File
0, 9, B, C, D, J, M, Q, R, S
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.215
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 212.043α = 90
b = 299.414β = 90
c = 575.197γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
SCALEPACKdata scaling
CNSrefinement
HKL-2000data reduction
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2005-11-29
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Non-polymer description, Version format compliance
