9FL1 | pdb_00009fl1

Apo Glyceraldehyde 3-phosphate Dehydrogenase (GapA) from Helicobacter pylori

PDB DOI: https://doi.org/10.2210/pdb9FL1/pdb

Classification: OXIDOREDUCTASE
Organism(s): Helicobacter pylori 26695
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-06-04 Released: 2025-06-18
Deposition Author(s): Elliott, P.R., Moody, P.C.E.
Funding Organization(s): Medical Research Council (MRC, United Kingdom)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.74 Å
R-Value Free:
0.200 (Depositor), 0.208 (DCC)
R-Value Work:
0.150 (Depositor), 0.164 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

structure and coenzyme specificity of a Helicobacter pylori glyceraldehyde 3-phosphate dehydrogenase (GapA)

Foster, S., Eliott, P.R., Basran, J., Moody, P.C.E.

To be published.

Macromolecule Content

Total Structure Weight: 145.53 kDa
Atom Count: 11,093
Modeled Residue Count: 1,269
Deposited Residue Count: 1,320
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glyceraldehyde-3-phosphate dehydrogenase (Gap)	A, B, C, D	330	Helicobacter pylori 26695	Mutation(s): 0 Gene Names: HP_1346
UniProt
Find proteins for O25902 (Helicobacter pylori (strain ATCC 700392 / 26695)) Explore O25902 Go to UniProtKB: O25902
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O25902
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EPE Query on EPE Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain H [auth B] SDF format, chain M [auth C] SDF format, chain R [auth D] MOL2 format, chain E [auth A] MOL2 format, chain H [auth B] MOL2 format, chain M [auth C] MOL2 format, chain R [auth D] mmCIF format, chain E [auth A] mmCIF format, chain H [auth B] mmCIF format, chain M [auth C] mmCIF format, chain R [auth D]	E [auth A], H [auth B], M [auth C], R [auth D]	4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID C₈ H₁₈ N₂ O₄ S JKMHFZQWWAIEOD-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain H [auth B] Focus chain M [auth C] Focus chain R [auth D] Interactions & Density Focus chain E [auth A] Focus chain H [auth B] Focus chain M [auth C] Focus chain R [auth D]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain Q [auth C] SDF format, chain I [auth B] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain N [auth C] SDF format, chain O [auth C] SDF format, chain P [auth C] MOL2 format, chain G [auth A] MOL2 format, chain Q [auth C] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain N [auth C] MOL2 format, chain O [auth C] MOL2 format, chain P [auth C] mmCIF format, chain G [auth A] mmCIF format, chain Q [auth C] mmCIF format, chain I [auth B] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain N [auth C] mmCIF format, chain O [auth C] mmCIF format, chain P [auth C]	G [auth A] I [auth B] J [auth B] K [auth B] L [auth B] G [auth A], I [auth B], J [auth B], K [auth B], L [auth B], N [auth C], O [auth C], P [auth C], Q [auth C]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth C] Interactions & Density Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Focus chain Q [auth C]
