9H4T | pdb_00009h4t

Crystal Structure of TorA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.86 Å
  • R-Value Free:
    0.289 (Depositor), 0.288 (DCC)
  • R-Value Work:
    0.235 (Depositor), 0.239 (DCC)
  • R-Value Observed:
    0.236 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Purification and Electron Transfer from Soluble c-Type Cytochrome TorC to TorA for Trimethylamine N-Oxide Reduction.

Panwar, A.Martins, B.M.Sommer, F.Schroda, M.Dobbek, H.Iobbi-Nivol, C.Jourlin-Castelli, C.Leimkuhler, S.

(2024) Int J Mol Sci 25

  • DOI: https://doi.org/10.3390/ijms252413331
  • Primary Citation of Related Structures:
    9H4T

  • PubMed Abstract:

    The enterobacterium Escherichia coli present in the human gut can reduce trimethylamine N-oxide (TMAO) to trimethylamine during anaerobic respiration. The TMAO reductase TorA is a monomeric, bis-molybdopterin guanine dinucleotide (bis-MGD) cofactor-containing enzyme that belongs to the dimethyl sulfoxide reductase family of molybdoenzymes. TorA is anchored to the membrane via TorC, a pentahemic c -type cytochrome which receives the electrons from the menaquinol pool. Here, we designed an expression system for the production of a stable soluble form of multiheme-containing TorC, providing, for the first time, the purification of a soluble pentahemic cytochrome- c from E. coli . Our focus was to investigate the interaction between TorA and soluble TorC to establish the electron transfer pathway. We solved the X-ray structure of E. coli TorA and performed chemical crosslinking of TorA and TorC. Another goal was to establish an activity assay that used the physiological electron transfer pathway instead of the commonly used unphysiological electron donors methylviologen or benzylviologen. An AlphaFold model including the crosslinking sites provided insights into the electron transfer between TorC C and the active site of TorA.


  • Organizational Affiliation
    • Department of Molecular Enzymology, Institute of Biochemistry and Biology, University of Potsdam, Karl-Liebknecht Str. 24-25, 14476 Potsdam, Germany.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Trimethylamine-N-oxide reductase 1
A, B
848Escherichia coliMutation(s): 0
Gene Names: torAb0997JW0982
EC: 1.7.2.3
UniProt
Find proteins for P33225 (Escherichia coli (strain K12))
Explore P33225
Go to UniProtKB:  P33225
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP33225
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PGD (Subject of Investigation/LOI)
Query on PGD

Download Ideal Coordinates CCD File
C [auth A],
D [auth A],
Y [auth B],
Z [auth B]
2-AMINO-5,6-DIMERCAPTO-7-METHYL-3,7,8A,9-TETRAHYDRO-8-OXA-1,3,9,10-TETRAAZA-ANTHRACEN-4-ONE GUANOSINE DINUCLEOTIDE
C20 H24 N10 O13 P2 S2
SOFMTHSWCZNJTQ-ILXWUORBSA-N
1PE
Query on 1PE

Download Ideal Coordinates CCD File
DA [auth B]PENTAETHYLENE GLYCOL
C10 H22 O6
JLFNLZLINWHATN-UHFFFAOYSA-N
PGE
Query on PGE

Download Ideal Coordinates CCD File
CA [auth B],
EA [auth B],
L [auth A],
M [auth A],
N [auth A]
TRIETHYLENE GLYCOL
C6 H14 O4
ZIBGPFATKBEMQZ-UHFFFAOYSA-N
MLT
Query on MLT

Download Ideal Coordinates CCD File
FA [auth B]
GA [auth B]
HA [auth B]
O [auth A]
P [auth A]
FA [auth B],
GA [auth B],
HA [auth B],
O [auth A],
P [auth A],
Q [auth A],
R [auth A]
D-MALATE
C4 H6 O5
BJEPYKJPYRNKOW-UWTATZPHSA-N
PEG
Query on PEG

Download Ideal Coordinates CCD File
BA [auth B]
F [auth A]
G [auth A]
H [auth A]
I [auth A]
BA [auth B],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
IA [auth B],
J [auth A],
JA [auth B],
K [auth A],
S [auth A],
T [auth A],
U [auth A],
V [auth A],
W [auth A],
X [auth A]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
6MO (Subject of Investigation/LOI)
Query on 6MO

Download Ideal Coordinates CCD File
AA [auth B],
E [auth A]
MOLYBDENUM(VI) ION
Mo
HCNGUXXTNNIKCQ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.86 Å
  • R-Value Free:  0.289 (Depositor), 0.288 (DCC)
  • R-Value Work:  0.235 (Depositor), 0.239 (DCC)
  • R-Value Observed: 0.236 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 93.662α = 90
b = 117.467β = 103.25
c = 100.053γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
autoXDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research Foundation (DFG)GermanyEXC 2008-390540038

Revision History  (Full details and data files)

  • Version 1.0: 2025-02-26
    Type: Initial release
