9MLK | pdb_00009mlk

Post-fusion HERV-K Envelope Protein in complex with Kenv-4 Fab


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.84 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Human endogenous retrovirus K (HERV-K) envelope structures in pre- and postfusion by cryo-EM.

Shek, J.Sun, C.Wilson, E.M.Moadab, F.Hastie, K.M.Rajamanickam, R.R.Penalosa, P.J.Harkins, S.S.Parekh, D.Hariharan, C.Zyla, D.S.Yu, C.Shaffer, K.C.L.Lewis, V.I.Avalos, R.D.Mustelin, T.Saphire, E.O.

(2025) Sci Adv 11: eady8168-eady8168

  • DOI: https://doi.org/10.1126/sciadv.ady8168
  • Primary Citation of Related Structures:
    9MLA, 9MLK, 9O4F

  • PubMed Abstract:

    Human endogenous retroviruses (HERVs) are remnants of ancient infections that comprise ~8% of the human genome. The HERV-K envelope glycoprotein (Env) is aberrantly expressed in cancers, autoimmune disorders, and neurodegenerative diseases, and is targeted by patients' own antibodies. However, a lack of structural information has limited molecular and immunological studies of the roles of HERVs in disease. Here, we present cryo-electron microscopy structures of stabilized HERV-K Env in the prefusion conformation, revealing a distinct fold and architecture compared to HIV and simian immunodeficiency virus. We also generated and characterized a panel of monoclonal antibodies with subunit and conformational specificity, serving as valuable research tools. These antibodies enabled structure determination of the postfusion conformation of HERV-K Env, including its unique "tether" helix, and antibody-bound prefusion Env. Together, these results provide a structural framework that opens the door to mechanistic studies of HERV-K Env and tools for its evaluation as a potential therapeutic target.


  • Organizational Affiliation
    • Center for Vaccine Innovation, La Jolla Institute for Immunology, La Jolla, CA 92037, USA.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Kenv-4 Fab Heavy ChainA [auth H],
C [auth I],
E [auth J]
449Mus musculusMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Kenv-4 Fab Light ChainB [auth L],
D [auth M],
F [auth N]
213Mus musculusMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Transmembrane proteinG [auth A],
H [auth C],
I [auth B]
135Homo sapiensMutation(s): 0
Gene Names: ERVK-6ERVK6
UniProt
Find proteins for Q69384 (Homo sapiens)
Explore Q69384
Go to UniProtKB:  Q69384
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ69384
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.84 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC4.6
MODEL REFINEMENTPHENIX1.21.1_5286

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other privateUnited States13502-01-000-408
Other privateUnited States18030-01-000-408

Revision History  (Full details and data files)

  • Version 1.0: 2025-07-30
    Type: Initial release
  • Version 1.1: 2025-09-03
    Changes: Data collection, Database references
