9ED4 | pdb_00009ed4

A composite map of mTORC1-Rag-Ragultor-4EBP1 on membrane


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.23 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural basis for mTORC1 activation on the lysosomal membrane.

Cui, Z.Esposito, A.Napolitano, G.Ballabio, A.Hurley, J.H.

(2025) Nature

  • DOI: https://doi.org/10.1038/s41586-025-09545-3
  • Primary Citation of Related Structures:
    9ED4, 9ED6, 9ED7, 9ED8

  • PubMed Abstract:

    The mechanistic target of rapamycin complex 1 (mTORC1) integrates growth factor (GF) and nutrient signals to stimulate anabolic processes connected to cell growth and inhibit catabolic processes such as autophagy 1,2 . GF signalling through the tuberous sclerosis complex regulates the lysosomally localized small GTPase RAS homologue enriched in brain (RHEB) 3 . Direct binding of RHEB-GTP to the mTOR kinase subunit of mTORC1 allosterically activates the kinase by inducing a large-scale conformational change 4 . Here we reconstituted mTORC1 activation on membranes by RHEB, RAGs and Ragulator. Cryo-electron microscopy showed that RAPTOR and mTOR interact directly with the membrane. Full engagement of the membrane anchors is required for optimal alignment of the catalytic residues in the mTOR kinase active site. Converging signals from GFs and nutrients drive mTORC1 recruitment to and activation on lysosomal membrane in a four-step process, consisting of (1) RAG-Ragulator-driven recruitment to within ~100 Å of the lysosomal membrane; (2) RHEB-driven recruitment to within ~40 Å; (3) RAPTOR-membrane engagement and intermediate enzyme activation; and (4) mTOR-membrane engagement and full enzyme activation. RHEB and membrane engagement combined leads to full catalytic activation and structurally explains GF and nutrient signal integration at the lysosome.


  • Organizational Affiliation
    • Department of Molecular and Cell Biology, University of California, Berkeley, Berkeley, CA, USA.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Target of rapamycin complex subunit LST8A [auth B],
M
326Homo sapiensMutation(s): 0
Gene Names: MLST8GBLLST8
UniProt & NIH Common Fund Data Resources
Find proteins for Q9BVC4 (Homo sapiens)
Explore Q9BVC4
Go to UniProtKB:  Q9BVC4
PHAROS:  Q9BVC4
GTEx:  ENSG00000167965
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BVC4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
GTP-binding protein RhebB [auth L],
N
184Homo sapiensMutation(s): 0
Gene Names: RHEBRHEB2
EC: 3.6.5
UniProt & NIH Common Fund Data Resources
Find proteins for Q15382 (Homo sapiens)
Explore Q15382
Go to UniProtKB:  Q15382
PHAROS:  Q15382
GTEx:  ENSG00000106615
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15382
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Serine/threonine-protein kinase mTORC [auth A],
O
2,549Homo sapiensMutation(s): 0
Gene Names: MTORFRAPFRAP1FRAP2RAFT1RAPT1
EC: 2.7.11.1 (PDB Primary Data), 2.7.10.2 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P42345 (Homo sapiens)
Explore P42345
Go to UniProtKB:  P42345
PHAROS:  P42345
GTEx:  ENSG00000198793
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP42345
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Ras-related GTP-binding protein A
D, P
313Homo sapiensMutation(s): 0
Gene Names: RRAGA
EC: 3.6.5
UniProt & NIH Common Fund Data Resources
Find proteins for Q7L523 (Homo sapiens)
Explore Q7L523
Go to UniProtKB:  Q7L523
PHAROS:  Q7L523
GTEx:  ENSG00000155876
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7L523
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Ragulator complex protein LAMTOR2E [auth G],
Q
125Homo sapiensMutation(s): 0
Gene Names: LAMTOR2MAPBPIPROBLD3HSPC003
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y2Q5 (Homo sapiens)
Explore Q9Y2Q5
Go to UniProtKB:  Q9Y2Q5
PHAROS:  Q9Y2Q5
GTEx:  ENSG00000116586
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Y2Q5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Ragulator complex protein LAMTOR3F [auth H],
R
124Homo sapiensMutation(s): 0
Gene Names: LAMTOR3MAP2K1IP1MAPKSP1PRO2783
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UHA4 (Homo sapiens)
Explore Q9UHA4
Go to UniProtKB:  Q9UHA4
PHAROS:  Q9UHA4
GTEx:  ENSG00000109270
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9UHA4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Ragulator complex protein LAMTOR5G [auth J],
S
91Homo sapiensMutation(s): 0
Gene Names: LAMTOR5HBXIPXIP
UniProt & NIH Common Fund Data Resources
Find proteins for O43504 (Homo sapiens)
Explore O43504
Go to UniProtKB:  O43504
PHAROS:  O43504
GTEx:  ENSG00000134248
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO43504
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Eukaryotic translation initiation factor 4E-binding protein 1H [auth K],
T
118Homo sapiensMutation(s): 0
Gene Names: EIF4EBP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q13541 (Homo sapiens)
Explore Q13541
Go to UniProtKB:  Q13541
PHAROS:  Q13541
GTEx:  ENSG00000187840
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13541
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Regulatory-associated protein of mTORI [auth C],
U
1,335Homo sapiensMutation(s): 0
Gene Names: RPTORKIAA1303RAPTOR
UniProt & NIH Common Fund Data Resources
Find proteins for Q8N122 (Homo sapiens)
Explore Q8N122
Go to UniProtKB:  Q8N122
PHAROS:  Q8N122
GTEx:  ENSG00000141564
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8N122
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Ras-related GTP-binding protein CJ [auth E],
V
399Homo sapiensMutation(s): 1
Gene Names: RRAGC
EC: 3.6.5
UniProt & NIH Common Fund Data Resources
Find proteins for Q9HB90 (Homo sapiens)
Explore Q9HB90
Go to UniProtKB:  Q9HB90
PHAROS:  Q9HB90
GTEx:  ENSG00000116954
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9HB90
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Ragulator complex protein LAMTOR1K [auth F],
W
161Homo sapiensMutation(s): 0
Gene Names: LAMTOR1C11orf59PDROPP7157
UniProt & NIH Common Fund Data Resources
Find proteins for Q6IAA8 (Homo sapiens)
Explore Q6IAA8
Go to UniProtKB:  Q6IAA8
PHAROS:  Q6IAA8
GTEx:  ENSG00000149357
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6IAA8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Ragulator complex protein LAMTOR4L [auth I],
X
99Homo sapiensMutation(s): 0
Gene Names: LAMTOR4C7orf59
UniProt & NIH Common Fund Data Resources
Find proteins for Q0VGL1 (Homo sapiens)
Explore Q0VGL1
Go to UniProtKB:  Q0VGL1
PHAROS:  Q0VGL1
GTEx:  ENSG00000188186
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ0VGL1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
IHP
Query on IHP

Download Ideal Coordinates CCD File
DA [auth A],
MA [auth O]
INOSITOL HEXAKISPHOSPHATE
C6 H18 O24 P6
IMQLKJBTEOYOSI-GPIVLXJGSA-N
GSP
Query on GSP

Download Ideal Coordinates CCD File
HA [auth N],
Y [auth L]
5'-GUANOSINE-DIPHOSPHATE-MONOTHIOPHOSPHATE
C10 H16 N5 O13 P3 S
XOFLBQFBSOEHOG-UUOKFMHZSA-N
GTP
Query on GTP

Download Ideal Coordinates CCD File
EA [auth D],
NA [auth P]
GUANOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O14 P3
XKMLYUALXHKNFT-UUOKFMHZSA-N
ANP
Query on ANP

Download Ideal Coordinates CCD File
AA [auth A],
JA [auth O]
PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER
C10 H17 N6 O12 P3
PVKSNHVPLWYQGJ-KQYNXXCUSA-N
GDP
Query on GDP

Download Ideal Coordinates CCD File
GA [auth E],
PA [auth V]
GUANOSINE-5'-DIPHOSPHATE
C10 H15 N5 O11 P2
QGWNDRXFNXRZMB-UUOKFMHZSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
BA [auth A]
CA [auth A]
FA [auth D]
IA [auth N]
KA [auth O]
BA [auth A],
CA [auth A],
FA [auth D],
IA [auth N],
KA [auth O],
LA [auth O],
OA [auth P],
Z [auth L]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.23 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX
MODEL REFINEMENTCoot
MODEL REFINEMENTISOLDE
RECONSTRUCTIONcryoSPARC4.4

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesCA285366

Revision History  (Full details and data files)

  • Version 1.0: 2025-09-10
    Type: Initial release
  • Version 1.1: 2025-10-01
    Changes: Data collection, Database references
